Toray TMG10D 2850 gpd Brackish Water Membrane 4 x 40

The Toray TMG10D 2850 gpd Brackish Water Membrane is designed to be used on water sources with low salinity (<2,000 ppm). They can be used in multiple membrane systems to treat municipal, industrial, commercial or process water.

Specifications:

Permeate Flow Rate: 2850 Gallons per day
Membrane Type: Polyamide composite
Applied Pressure: 150 psi
Dimensions: 4" x 40"
Salt Rejection: 99.7%
Chlorine Tolerance: 0 ppm
Maximum Operating Temperature: 113° F
Applications: Tap water, brackish water, well water, surface water

Compatible with:

CSM Membranes	RE4040 BLN, RE4040 BLR
Filmtec Membranes	BW30LE-4040, LE-4040, LP-4040, LC LE 4040
GE Water	AK4040FF, 1206813
Hydranautics Membranes	ESPA1-4040
TriSep Membranes	4040-ACM3-TSF, 4040-ACM3-TSA, 4040-ACM4-TSF, 4040-ACM4-TSA, 4040-ACM5-TWF
Watts	R9622-WLE

Product Details
Active Area	87 sq. ft.
Average Nacl Rejection	0.99
Chlorine Tolerance	<0.1ppm
Cleaning Ph Range	1-13
Direction	Outside - In
Feed Spacer Thickness	31 mil
Feed Water Concentration	2000 mg/l Nacl
Feed Water Temperature	77°F
Inlet Pressure	150 PSI
Material Of Construction	Cross-Linked Polyamide
Max Feed Silt Density Index	5 Silt Density Index
Max Pressure Drop	15 PSI per Element PSI Differential
Max Pressure (Psi)	365 psi
Max Temp (°F)	113°F
Membrane Type	Spiral Wound
Min Flow Rate	2,400 gpd (9.1m3 /d)
Minimum Salt Rejection Cl- (%)	0.995
Permeate Flow Rate	2,850 gpd (10.8)
Permeate Tube Diameter	3/4"
Ph Range	2-11
Recovery Rate	0.15
Stabilized Salt Rejection Cl- (%)	0.997
Diameter	4"
Origin	U.S.A.
Shipping Dimensions
Shipping Length	43 in.
Shipping Width	5.5 in.
Shipping Height	5.5 in.
Product Weight & Dimensions
Product Height	5.5 in.
Product Length	43 in.
Product Width	5.5 in.
Product Weight (lbs)	9.45

Toray TMG10D 2850 gpd Brackish Water Membrane 4 x 40 Manual
