Home / Pumps & Motors / Rotary Vane Pumps & Motors / Procon Pump NSF Stainless Steel 190 GPH 1/2" NPT - 250 psi w/ 1143 Bronze Coupling (Clamp-on)
Procon

Procon Pump NSF Stainless Steel 190 GPH 1/2" NPT - 250 psi w/ 1143 Bronze Coupling (Clamp-on)

Part Number: BACD16004MBLK
Alt. Part Number: 115B190R31XX
out of stock
Product image 1 Product image 2 Product image 3
This item is discontinued. We recommend the BACD16004 Valved In-Line Panel Mount Hose Barb BreakAway Coupling Body 1/4 ID Barb as a substitute.
MSRP: $16.90
Your price:
$16.90
Product not eligible for free shipping. Learn more
Choose
Single
Pack of 4
Pack of 9
similar items
BACD16004MBLK Valved In-Line Panel Mount Hose Barb BreakAway Coupling Body Molded Black - 1/4 ID Barb
BACD16004MBLK Valved In-Line Panel Mount Hose Barb BreakAway Coupling Body Molded Black - 1/4 ID Barb
$16.90
 BACD16004MBLK Valved In-Line Panel Mount Hose Barb BreakAway Coupling Body Molded Black - 1/4 ID Barb
BACD16004MBLK Valved In-Line Panel Mount Hose Barb BreakAway Coupling Body Molded Black - 1/4 ID Barb
$16.90
The Procon Pump NSF Stainless Steel 190 GPH 1/2" NPT - 250 psi w/ 1143 Bronze Coupling (Clamp-on) is a positive displacement pump. This Series 5 Procon pump is stainless steel with 1143 Bronze Coupling. The inlet and outlet ports are 1/2" NPT and the pump has a flow-rate of 190 gallons per hour. The seal configuration for the 105B190F31XX uses Nitrile Type 21 which will prevent leakage. The clockwise rotation of the pump operates at a nominal speed of 1725 rotations per minute. The Series 5 pumps are self-priming, so there is virtually no maintenance. The maximum discharge pressure for this pump is 250 PSI. The 105B190F31XX pump is designed to be directly connected to the motor with a stainless steel clamp.

Features:
  • Leak-free.
  • The seal configuration uses Nitrile Type 21, which will prevent leakage.
  • NSF Certified
  • NSF/Ansi Standard 169 for special purpose food equipment and devices.
  • Typical Applications. Beverage, espresso/coffee, cold carb circulation, reverse osmosis, beer chillers, pesticide systems, and solar applications.
  • Low Maintenance. The Series 5 pumps are self-priming, so there is virtually no maintenance.
