John Guest Brass Female Connector (Garden Hose) - 1/4 x 3/4 - 11.5 NH

The John Guest female connector is used for connecting the cold-water supply to coffee machines and equipment and is also used in beverage dispensing and vending machine applications. For connecting OD tubing sizes to male garden hose threads. John Guest Push-fit technology makes connecting tubing quick and easy. Constructed of Lead-Free Brass with an EPDM O-ring.

Features and benefits:

For use with plastic or copper OD sized tubing
Lead Free Brass body, EPDM O-ring
Quick and easy connection/disconnection
NSF61 listed

Working pressure and temperature:

150 psi at 70° F
60 psi at 140° F

Product Details
Application	Water Food Beverage
Body Material	Brass
Inlet Connection	3/4" GHT
Max Pressure (Psi)	150
Max Temp (°F)	140
Min Pressure (Psi)	0
Min Temp (°F)	33
Mounting Options	Thread
Outlet Connection	3/4" GHT
Push-In Size	1/4" OD
Seal Material	EPDM
Series	NC-Brass
Shape	Straight
Size	3/4"
Color / Finish	Brass
Connection Type	GHT
Origin	UK
Sub-Type	Hose Adapter
Type	Adapter
Warranty & Certifications
Product Certification Standard	NSF/ANSI 61

John Guest Brass Female Connector (Garden Hose) - 1/4 x 3/4 - 11.5 NH Manual
